61201021621
Manufacturer:
Wurth Electronics
Mfr.Part #:
61201021621
Datasheet:
Description:
Headers and Wire Housings Through Hole Male Pin Number of Positions:10 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 250 V |
| Length | 9.1 mm |
| Width | 20.36 mm |
| Termination | Solder |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 10 |
| Height | 8.85 mm |
| Packaging | Tray |
| Voltage Rating | 250 V |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| Insulation Resistance | 1 GΩ |
| REACH SVHC | Unknown |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Copper |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Flammability Rating | UL94 V-0 |
| Orientation | Vertical |
| Operating Supply Voltage | 250 V |
| Color | Black |
| Gender | Male |
| Number of Contacts | 10 |
| Connector Type | Male Pin |
| Number of Positions | 10 |
| Number of Rows | 2 |
| Row Spacing | 2.54 mm |
| Housing Material | PBT |
| Contact Resistance | 20 mΩ |
| Contact Gender | Male |
| Termination Post Length | 3 mm |
Stock: 20977
Distributors
pcbx
pcbxUnit Price$0.26934
Ext.Price$0.26934
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.26934 | $0.26934 |
| 10 | $0.26215 | $2.62150 |
| 25 | $0.25195 | $6.29875 |
| 50 | $0.24215 | $12.10750 |
| 100 | $0.21680 | $21.68000 |
